1.2mm Thickness Imitation Wood Roller Coated Aluminum Coil
Wood texture coated aluminum coil is a decorative building material that replicates the natural
appearance of wood through advanced roller coating or transfer printing techniques.It combines
the durability of metal with the aesthetic appeal of wood, making it ideal for modern architectural
applications.
Key Features
• Realistic Wood Effect: High-definition patterns (e.g., teak, oak, walnut) with textured finishes.
• Lightweight & Strong: Aluminum core (density: ~2.71g/cm³) ensures structural stability with
minimal weight.
• Weather Resistance: PVDF (for outdoor) or PE (for indoor) coatings provide UV protection,
corrosion resistance, and a lifespan of 10-20 years.
• Eco-Friendly: 100% recyclable, formaldehyde-free, compliant with LEED/GREEN standards.
• Easy Installation: Supports bending, punching, and mechanical fixing (e.g., riveting, dry-hanging).
Recommended Thickness by Application
| Application | Recommended Thickness | Rationale |
| Interior ceilings/walls | 0.5mm-0.8mm | Lightweight, cost-saving |
| Low-rise building facades | 1.0mm-1.5mm | Basic wind load requirements |
| High-rise/coastal facades | 2.0mm-3.0mm | Withstands strong winds/salt spray |
| Furniture/cabinet panels | 0.4mm-0.7mm | Easy fabrication, smooth finish |
| Outdoor canopies/railings | 1.2mm-2.5mm | High weather resistance needed |
Our Company Advantages and Production Range
Advanced Equipment
• German SMS Group fully automated coating lines with ±0.01mm thickness precision,
Line Speed: 120m/min (20% faster than industry average)
• MES system enables real-time production monitoring with ≥99.3% product qualification rate
• Multi-spectral imaging detects micro-defects as small as 0.02mm² with 99.8% recognition accuracy
Technology Patents
♦ Anti-Static Color Aluminum Coil and Continuous Production System
♦ Chromium-Free Passivation Solution for Color-Coated Aluminum Coils and Preparation Method
♦ Production Process for High Solar-Reflectance Color Aluminum Coils
♦ Method for Preparing 3D Wood Grain Aluminum Coil Based on Nanoimprint Technology
♦ Low-Temperature Curing Technology
| Thickness Range | 0.20 - 5.0mm |
| Width Range | Max. 1800mm |
| Alloy | 1050,1060, 3003, 3004,3105,5052 |
| Paint System | PE, SMP, PVDF |
| Color Options | RAL color or as the sample |
